Installation Guides

Step-by-step instructions for every component in our glass railing systems. From spigot mounting to connector finishing. Call us directly at (206) 420-6678 for more information!

Before You Begin

Installation Overview

1

Prepare Your Substrate

Ensure your mounting surface (concrete, wood deck, or steel) is level and structurally sound. Mark spigot locations every 3 feet along the railing run.

2

Mount Spigots

Drill holes according to the bolt pattern. Insert anchors for concrete, or use lag bolts for wood. Tighten spigots to the specified torque.

3

Set Glass Panels

Slide panels into spigots and tighten set screws. Use a level to ensure panels are plumb. Connect adjacent panels with 180° connectors.

4

Finish with Cap Rail

If using a cap rail, measure and cut to length. Snap onto the glass top edge and secure with clips at each spigot point. Add end caps and corner connectors.

For Contractors & Installers

Installation Guides

Tools You'll Need

Hammer drill with masonry bits for concrete substrates
Standard drill/driver for wood or steel substrates
Socket wrench set
Torpedo level and 4 ft. level
Tape measure
Pencil or marker
Safety glasses and gloves
Miter saw with a non-ferrous blade for cutting cap rail

Substrate Preparation

Our spigots can be installed on concrete, wood, or steel. Each substrate requires the appropriate fastening method to ensure a secure installation.

Concrete: Use the supplied concrete anchors. Drill each hole to the required depth using a hammer drill and masonry bit. Thoroughly clean the holes before installing the anchors.
Wood: Fasten through the deck board and securely into the supporting joist below. We recommend a minimum 2x8 joist for proper structural support. Pre-drill pilot holes to help prevent splitting.
Steel: Use suitable through-bolts with backing plates where required. Drill the substrate to match the spigot's mounting pattern.

Always ensure the mounting surface is structurally sound and capable of supporting the railing system.

Spigot Spacing

Proper spigot placement helps provide both a clean appearance and secure glass support. Follow the spacing chart provided with your order for exact placement.

As a general guideline:

Panels up to 36" wide typically use 2 spigots
Position spigots near each end of the panel
Use a 180° connector between panels on straight runs
Use a 90° connector at corners
Use a wall connector where the railing meets a wall

Spacing requirements can vary depending on your glass size, configuration, and local building requirements.

Glass Panel Installation

Make sure each spigot is securely anchored and properly aligned.
Loosen the spigot set screws enough to allow the glass to slide into position.
Carefully lower the glass panel into the spigots.
Use a level to check that the panel is properly aligned and plumb.
Once positioned correctly, tighten the set screws evenly to secure the glass.
Install the appropriate connectors between adjacent panels.

Never force or modify glass panels during installation.

Cap Rail Installation

Measure each railing section carefully before cutting.
Cut the aluminum cap rail to length using a miter saw with a non-ferrous blade.
Insert the rubber gasket into the cap rail channel.
Carefully press the cap rail onto the top edge of the glass.
Secure the rail using the supplied clips or hardware.
Finish with end caps and corner connectors where required.

Tip: Measure each section individually, especially around corners and wall connections, to ensure an accurate fit.

Contact Us

Need Help?

Not sure about your measurements, spigot placement, or installation method? Give us a call at (206) 420-6678, we're here to help.

Whether you're working on stairs, corners, curves, or a multi-level project, our team can talk through your project, help you determine the right components, and answer your questions before you begin installation.

Have questions? Call us today and let's get your project on the right track.

Always verify your local building code requirements before installation.
